The most advanced solution to replace your fluorinated polymer coatings
Advanced nanoGUARD coatings reach ready state within 30-60 seconds in ambient temperatures, requiring no ovens or curing process. Additionally, nanoGUARD’s unique gel-state eliminates the need for masking connectors, contacts and components with connect-through capability and enables undercoating of components, including BGAs for 100% surface protection.
| Property | ANG 112 | ANG Titan | Fluoro-Polymers |
|---|---|---|---|
| Solvent | C7 – C8 Isoalkanes 81 wt | C7 – C8 Isoalkanes 70 wt | Fluorinated solvent |
| Viscosity | 4.7-5.5 cP @ 25° C | 4.7-5.5 cP @ 25° C | 1-2 cP |
| Coating Thickness | 5-100 μm (depending on required protection) | 5-100 μm (depending on required protection) | 0.1 - 4.0 μm (depending on application method) |
| Solvent & Chemical Resistance | Resists a variety of fluids including water, saltwater, soapy water, Coke, Gatorade, coffee, salt, windshield washer fluid, coolant, mixed flowing gas, sweat | Resists a variety of fluids including water, saltwater, soapy water, Coke, Gatorade, coffee, salt, windshield washer fluid, coolant, mixed flowing gas, sweat | Resists a variety of solvents and chemicals |
| Operating Temperature | Operating Temperature | -40 to +200 °C | Up to 175 °C for 24 hours |
| Tg (Glass Transition Temperature) | No glass transition down between -60 and +200 °C | No glass transition down between -60 and +200 °C | 44-53 °C (127 °F) |
| Contact Angle (Static, Water) | 108° | 102° | 105° |
| Reworkability | Can be easily removed to repair and replace components | Can be easily removed to repair and replace components | Requires fluorinated solvent to remove |
| Non-Flammable | Meets UL 94 V-0 | Meets UL 94 V-0 | Meets UL 94 V-0 |
| Coefficient of Thermal Expansion | ANG gel-state creates no inherent stress on components or solder joints | ANG gel-state creates no inherent stress on components or solder joints | 70-90 μm/(m· °C) |
| Thermal Conductivity | 0.15-0.18 W/m·K | 0.15-0.18 W/m·K | 0.1 W/m·K |
| Dielectric Constant @30% RH PER ASTM D150 | 3.01 (@500 MHz) | 3.23 (@500 MHz) | 3.2 (@1 kHz) |
