Validation Data

Proven Performance

Download PDF

Advanced nanoGUARD™ coatings provide critical electronics applications with 3D protection from harsh electrical and environmental conditions.

actnano’s proven nanoGUARD technology delivers unsurpassed performance, reliability and manufacturing efficiencies without compromise.

// Coverage

100% 3D coverage with nanoGUARD viscoelastic, gel-state material

  • Horizontal and vertical surfaces
  • Undercoat large components (BGAs, etc)
  • Use on rigid or flexible substrates
  • No cracking or bubbling

// Reliability

Waterproof exceeding IPX7/8+

  • Protection from liquids, condensation, humidity, salt and more

Proven connect through coating capability

  • No/minimal masking required
  • Coat connectors and contacts
  • Maintain high speed signal integrity connections

// RF & Thermal

Coat heat sinks and antennas

  • No RF influence
  • Negligible thermal impact

// Efficiency

Lowest total solution cost

  • In-line processing, no cure time deposition
  • No ovens or other curing required
  • Use existing or standard equipment
  • Typically, ready within 30-60 seconds
  • Easy board rework and repair

// Compliance

Meets a broad list of environmental certifications and industry requirements

  • UL94 V-0 and UL94 5VA flammability rating
  • 100% safe materials
  • Lower manufacturing carbon footprint

Proven Performance

Water protection:

IPX7/IPX8+

Humidity:

85C @ 95% RH @ 1,000 hours

Thermal Shock:

125 C/-40 C 1,000 cycles

Salt fog:

24-hr 72-hr, 96-hr, 200-hr under 48V

Submersion:

Water – 1 meter, 30 minutes
Saltwater (3.5% NaCL) – 15 hours
Soap water (1% soap solution) – 15 hours

RF:

No signal attenuation up to 60 GHz

Electrical Contact:

No change within measurable tolerance

The Process Advantage

  • Use existing equipment
  • No ovens or curing required
  • No masking or demasking
  • Coat over connectors
  • Fast ambient cure
  • Easy and fast rework

// RF & Thermal

Rohs compliant logo
